您當前的位置：首頁 >> 機床附件和工裝夾具 >> 滾花工具 >> FORM ROLL >> FORM ROLL >> FORM ROLL 高速鋼滾花輪

FORM ROLL 高速鋼滾花輪

FORM ROLL 高速鋼滾花輪
優質·拋光齒

應用：
·用塔型車床滾花,直齒滾輪用于加工除陰性的所有滾花

用于 30-9 系列的滾花信息
用于生產-使用
右旋滾花-左旋滾花
左旋滾花-右旋滾花
陽性鉆石紋-使用一對(左,右各一只滾花輪)或陰性滾花輪
陰性鉆石紋-使用陽性鉆石紋滾花輪

普通圓形T.P.I.
---------------------------------------
直徑的螺距     直齒      30°螺旋
64            20.7        23.9
96            30.8        35.6
128           41.1        47.4
160           51.2        59.1

貨號	型號	滾花輪尺寸	加工范圍	直徑	寬度	砂輪直徑	孔尺寸	價格(1件起訂)			購買
								1	1	1
30-982-096				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-981-096				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-980-160				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-980-128				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-980-096				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-980-064				3/4"	3/8"	3/8"	1/4"	227.76	227.76	227.76
30-970-160				3/4"	1/4"	1/4"	1/4"	214.21	214.21	214.21
30-970-128				3/4"	1/4"	1/4"	1/4"	214.21	214.21	214.21
30-970-064				3/4"	1/4"	1/4"	1/4"	214.21	214.21	214.21
30-962-128				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-962-096				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-962-064				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-961-128				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-961-096				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-961-064				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-960-128				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-960-096				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-960-064				5/8"	1/4"	1/4"	1/4"	190.78	190.78	190.78
30-951-096				1/2"	3/16"	3/16"	3/16"	173.27	173.27	173.27
30-950-160				1/2"	3/16"	3/16"	3/16"	173.27	173.27	173.27
30-950-128				1/2"	3/16"	3/16"	3/16"	173.27	173.27	173.27
30-950-096				1/2"	3/16"	3/16"	3/16"	173.27	173.27	173.27
30-935-450				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-935-230				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-935-225				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-935-220				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-934-450				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-934-230				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-934-225				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-934-220				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-934-216				3/4"	3/8"	3/8"	1/4"	261.83	261.83	261.83
30-933-480				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-450				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-240				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-230				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-225				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-221				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-220				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-216				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-214				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-933-212				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-480				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-450				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-240				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-230				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-225				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-221				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-220				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-216				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-214				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-932-212				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-480				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-450				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-240				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-233				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-230				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-225				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-221				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-220				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-216				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-214				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-931-212				3/4"	3/8"	3/8"	1/4"	177.13	177.13	177.13
30-925-450				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-925-230				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-925-225				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-925-220				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-924-450				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-924-230				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-924-225				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-924-220				3/4"	1/4"	1/4"	1/4"	246.34	246.34	246.34
30-923-450				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-923-230				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-923-225				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-923-220				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-922-450				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-922-230				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-922-225				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-922-220				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-480				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-450				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-240				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-235				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-230				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-225				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-220				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-921-216				3/4"	1/4"	1/4"	1/4"	165.54	165.54	165.54
30-915-230				5/8"	1/4"	1/4"	1/4"	219.99	219.99	219.99
30-915-220				5/8"	1/4"	1/4"	1/4"	219.99	219.99	219.99
30-914-230				5/8"	1/4"	1/4"	1/4"	219.99	219.99	219.99
30-914-220				5/8"	1/4"	1/4"	1/4"	219.99	219.99	219.99
30-913-230				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-913-225				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-913-220				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-913-216				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-912-230				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-912-225				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-912-220				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-912-216				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-480				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-247				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-240				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-230				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-225				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-220				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-911-216				5/8"	1/4"	1/4"	1/4"	147.95	147.95	147.95
30-903-220				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-902-220				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-450				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-247				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-240				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-235				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-232				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-230				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-225				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
30-901-220				1/2"	3/16"	3/16"	3/16"	133.35	133.35	133.35
